PRODUCT PORTFOLIO OF
EURODUR® GMBH
cooler grills and other components for the cement industry
hoppers / clearing hoppers
wear resistant coatings for waste disposal trucks
highly wear resistant stripe coatings for extremely efficient wear resistance on
clearing hoppers
misc. guidance elements (rails, strips, rollers, …)
inner container shells (wall / base / trommel coatings)
press cones
press spiral conveyors
specialized parts based on clients specifications
welding consumables
In addition to delivering wear resistant products we are also able to do repairs and
overhauls to customer vehicles directly at our site. You do not find the desired products you are looking for? No problem – please call us anytime or contact us via email. Surely we will find a solution for you, even for the most complex challenges.
FOR MORE THAN 35 YEARS
WE ARE SPECIALIZED ON
QUALITY IS FOR KEY US
ABOVE ALL OTHER CRITERIA

PROCEDURES AND PRODUCTION
EXPLAINED
By using flux-cored welding wires we are able to achieve the highest possible coating
quality – reproducible every time. A very harmonious distribution of hard carbide in
the whole component part is the main characteristic, as well as a very low dilution of
the original base material. Adding a wear resistant layer on our specially developed EURODUR® build-up welding machinery guarantees highest quality and reliable protection against wear.
Excerpt of an expertise from ISAF:
“The microstructure of the coating is distributed very harmoniously. A very high
resistance against abrasive wear is to be expected.
The penetration zone is very evenly formed. A very low thermal interference with the
base material is to be expected.
The carbide quota is over 60%!
The carbides and their evenly formed distribution show an optimized cooling
procedure of the welding piece.
The carbide distribution measures near the absolute maximum saturation level which
is achievable using electric arc welding.”

WORTH KNOWING ABOUT OUR QUALITY CRITERIA
OF HARD SURFACING
Using the right welding consumables is key to build-up welding with maximum
quality and wear resistance. EURODUR® offers up to 14 different analysis
methods to perfectly match the field of application to the desired wear
resistance needed.
QUALITY UALITY CRITERIA IN DETAIL
Specially chosen, highest quality alloying parts
Components of the analysis
High carbide quota in the welding material
Evenly distributed microstructure
Low dilution of base material
Evenly high hardness profile
Finely distributed heat treatment cracks
Surface evenness
EURODUR® GmbH has set the standards in the industry, several times
proven bydifferent independent institutes. The German
“Institut für Schweißtechnik ISAF” (Institute for Welding Technology)
of The University Clausthal did several expertise on the work of EURODUR®.
In these expertise characteristics of different criteria were probed, like microstructure, carbide quota, dilution, hardness etc.
